1. Smooth Material Flow Direction
The guide plate channels milled asphalt or concrete material from the cutting drum onto the primary conveyor belt. Prevents material spillage, reduces belt wear, and ensures efficient discharge into trucks. Essential for highway milling, pavement recycling, and large-scale excavation projects requiring continuous material flow.
2. Compatible with Wirtgen Milling Machine Models
Direct bolt-on replacement for OEM guide plate on Wirtgen W1900/W2000/W2100/W2200 large milling machines and W120/W130/W150 compact milling machines. Often replaced alongside conveyor belt, return pulley (111225) , scraper plate, and wear strips to restore complete conveyor system performance.
3. Wear-Resistant Construction
Manufactured from abrasion-resistant steel plate with smooth surface finish to minimize material adhesion. Features pre-drilled mounting holes matching OEM specifications. For maximum conveyor reliability, inspect guide plate for wear during conveyor belt replacement and check scraper plate alignment.
Item | Details |
|---|---|
Part Number | 112519 |
Product Name | Smooth Flow Guide Plate / Material Guide Plate |
Brand Compatibility | Wirtgen |
Fit Models | W1900 / W2000 / W2100 / W2200 / W120 / W130 / W150 |
Weight | 6.8 kg |
Dimensions | 450 × 160 × 12 mm |
Material | Abrasion-resistant steel |
Surface Finish | Smooth, material-release coating |
Function | Material guidance from milling drum to conveyor |
Related Parts | Conveyor Belt, Return Pulley (111225), Scraper Plate, Wear Strip |
Warranty | 1 year |
Installation | Bolt-on replacement |
